While the electronic circuit theory behind VersaFuelerTM operation can be intimidating, you don't need to understand any of that to see how the VersaFuelerTM  can help you make big power with minimal cost.  In fact, my 9 year old grandson, Evan, made a poster that shows the VersaFueler's role in engine operation for his 3rd grade class.

ACCELERONICS FAQ

If the VersaFueler TM is patented, why do I see knockoffs on the market?

Will the VersaFueler TM run my stock injectors?

Is the VersaFueler TM hard to install?

My car has 4 or 6 (or 5, or 10) cylinders, can I use the Acceleronics VersaFueler TM?

Can I run big injectors on the street?

How do I tune my engine for low-impedance injectors?

Why can't I run low-impedance injectors with the factory computer?

What is the difference between low-impedance and high-impedance injectors?


If the VersaFueler TM is patented, why do I see knockoffs on the market?

United States patents are like locks, they keep honest people honest.  But just as a lock can be broken if a thief wants to steal your car, a patent can be ignored if a thief wants to steal your design.  And while most people agree that car thieves are bad and should be punished, many people don't think that someone who copies a patented design is a criminal.  Patent infringement court cases are extremely expensive, and can drag on forever.  We at Acceleronics hope that customers honor our patent by purchasing our product, not a knockoff sold by a patent infringer.  Not only is it patented, but the VersaFueler TM is also the most reliable and robust design on the market!

Back to Top


Will the VersaFueler TM run my stock injectors?

Yes!  The VersaFueler TM will run any gasoline injector!   Low impedance, high impedance, 19 lb/hr, 160 lb/hr, you name it we run it!

Back to Top


Is the VersaFueler TM? hard to install?

Not at all, it's easy!  The box simply splices between your ECU and injectors.  Connect one cylinder at a time to our color coded channels.  All the channels work the same, so any channel color can connect to any cylinder.  We even supply waterproof crimp splices!  Click here for the installation instructions.

Back to Top


My car has 4, 5, 6, or 10 cylinders, can I use the VersaFueler TM?

Yes!  The Acceleronics VersaFuelerTM has 8 channels, but you do not have to connect them all.  The 8 channels are all the same, so you can use whichever channels you want.  Acceleronics has 4 and 6-channel VersaFuelers TM priced to save you even more money!

Back to Top


Can I run big injectors on the street?

Yes!  Big injectors are streetable - the Acceleronics test car idled just fine at 900 rpm in gear with 95 lb/hr injectors running with 1.0 millisecond pulsewidths.  Throttle response on the street would just about snap the passenger's head off!  The 95 lb/hr injectors are as responsive as stockers.  We now stock 120 lb/hr flow matched injectors for you huge blower or turbo guys who like to push the envelope.

Back to Top


How do I tune my engine for low-impedance injectors?

Your ECU doesn't care whether the injectors are low-impedance, or high-impedance.  It only cares about how big they are, and how quickly they open.  You will need to change the number that tells your computer how big the new injectors are.  For example, when the Acceleronics Camaro changed from 50 lb/hr high-impedance injectors to 75 lb/hr low impedance injectors, we used LT1-Edit to change the "injector size" from 50 to 75.  Nothing to it!

If you removed larger-than-stock high-impedance injectors, your new injectors will probably open more quickly, so you may need another adjustment.  Again using the LT1-Edit example, we changed the values in the "injector offset versus voltage" table.  Your ECU may call it something else, but there is probably a similar offset number that tells the computer how snappy, or how sluggish, the injectors are.  Once the injector size and injector offset numbers are fixed, continue tuning as usual.

Back to Top


Why can't I run low-impedance injectors with the factory ECU?

Virtually all cars come with high-impedance injectors.  The ECU turns high impedance injectors on and off with a simple switch, much like an ordinary light switch.  Turn the switch on when you want fuel, turn it off when you don't.

But you can't run low-impedance injectors that way or you will burn them out!  These injectors need to be carefully controlled, so a simple on/off switch will not work.  They need something more like a dimmer switch.  Turn them on all the way to get them to open, then after they open, turn down the dimmer so they don't get too hot.

The second problem is that the ECU's injector drivers can't handle the large electric current needed for low-impedance injectors.  Low impedance injectors need about 4 times as much current as high-impedance injectors.  This much current will burn out the transistors in the ECU that run the injectors, unless the injectors burn out first!

The VersaFuelers TM is built to handle the needs of low impedance injectors, and to protect your ECU!

Back to Top


What is the difference between low-impedance and high-impedance injectors?

The important difference between low- and high-impedance injectors is the amount of electric current they require.  The high-impedance injectors used by carmakers do not use much current.  In fact, even if you connect one directly to your car's battery, it will not draw much juice.  This is good for the car maker because the circuit in the ECU that runs the injectors can be a simple switch made from cheap, light-duty components.

A low-impedance injector needs a bunch more electric current to open, about 4 times as much as the high-impedance injector.  This is so much current that the injector will burn itself out unless the juice is somehow turned down right after the injector opens.  Now, instead of a simple, cheap on/off switch, the ECU must use heavy-duty components that can handle 4 times as much current.  The switch must also turn down the flow of electricity after the injector opens so the injector doesn't burn up.  This is a much more expensive circuit, and one that generates a bunch more heat inside the computer.   Getting rid of that heat raises the computer cost even more.

This business of the ECU yanking the injector open with full current, then turning down the juice to keep it open, is why you hear low impedance injectors called "peak and hold".  It takes a big current (the peak) to yank them open, but a much smaller current (the hold) to keep them open.

So why bother with low-impedance injectors if they're harder to run?  Because bigger electric currents can yank harder than smaller ones.  As the flow rating of an injector increases, so does the weight of whatever the injector uses to turn the fuel on and off (for example, a pintle, or a disk).  This is no big deal for stock injectors in the 18 lb/hr to the 30 lb/hr range.  Even though they are high-impedance, they're light enough that the small current can yank them open quickly.

But big (like 42 lb/hr and up) high impedance injectors are slow to open.  This makes it hard to get a good idle, and kills throttle response.  What if you need an injector larger than 42 lb/hr?  Simple!   You buy low-impedance injectors, which are available up to 160 lb/hr.  The large peak current can quickly snap these monster injectors open.

So a low-impedance 50 lb/hr injector will almost certainly be "snappier" than a high-impedance 50 lb/hr injector.  When the 50 lb/hr high-impedance injectors on the Acceleronics test car were replaced with 75 lb/hr low-impedance injectors, the ECU setting that adjusts for "sluggishness" had to be set back to stock.  The high-impedance 50 lb/hr injectors required much more time to open than stockers, but the low-impedance 75 lb/hr injectors are just as snappy as stockers.

Back to Top

Written by Jeff Stevens.  Copyright © 2002-2008  Acceleronics.com   All rights reserved.  Revised: June 01, 2008.
